DESCRIPTION
Multi functional dimmer/switch pack equipped with 4 mains sockets (Schuko)Maximum output: 4x 1000W (Maxtot = 3450W/15A)Thanks to the well designed 19" brackets the DSP4 can be mounted in different ways:
Standard 19" rack mounting
Wall mount in fixed installations
Mounting under or inside ALU truss using clamps
Locking DMX in/outputs with POWER/DMX-present indicator5 Digit LED display with 4 buttons for easy menu navigation:
DMX address setting: each channel can have its own address
Each channel can be switched separately in dimmer or switch mode
Separate dimmer presets with memory function for each channel (no controller needed)
Mains power input with automatic 15A fuseIndividual channel 8A fusesAll channels equipped with 40A triacs for increased reliability
TECHNICAL INFORMATION
DMX channels: 4Size: 48,3 x 8,8 x 10cm (19' / 2U)Weight: 4,8 kg
DESCRIPTION
Multi functional dimmer/switch pack equipped with 4 mains sockets (Schuko)
Maximum output: 4x 1000W (Maxtot = 3450W/15A)
Thanks to the well designed 19" brackets the DSP4 can be mounted in different ways:
- Standard 19" rack mounting
- Wall mount in fixed installations
- Mounting under or inside ALU truss using clamps
Locking DMX in/outputs with POWER/DMX-present indicator
5 Digit LED display with 4 buttons for easy menu navigation:
- DMX address setting: each channel can have its own address
- Each channel can be switched separately in dimmer or switch mode
- Separate dimmer presets with memory function for each channel (no controller needed)
Mains power input with automatic 15A fuse
Individual channel 8A fuses
All channels equipped with 40A triacs for increased reliability
TECHNICAL INFORMATION
DMX channels: 4
Size: 48,3 x 8,8 x 10cm (19' / 2U)
Weight: 4,8 kg
