MARTIN AUDIO Blackline F12+
Garantiramo najnižu cijenu na tržištu!
U slučaju da pronađete isti proizvod po povoljnijoj cijeni,
molimo Vas da nas kontaktirate na:
info@player.hr
The LF driver has a tough, water resistant cone and features a high BL motor with a flat-wire copper coil and an aluminium demodulating ring. This reduces intermodulation distortion and improves midrange performance when driven hard. Increased excursion is available by virtue of a triple roll surround and deep motor structure. The directivity of the LF driver has been matched to the HF horn in the crossover region by improved crossover design and cone profile optimisation, also the new HF compression driver utilises an ultra-lightweight Kapton diaphragm for extended high frequency response.
A Martin Audio M3+ or DX1.5 Electronic Controller is available to provide F12+/subwoofer crossover and limiter facilities.
- Compact two-way passive system
- User rotatable 80° x 50° horn
- Top hat fitting for speaker stand mounting
- Five year limited warranty
| TYPE | Compact, two-way passive |
| FREQUENCY RESPONSE (5) | 65Hz-18kHz ± 3dB -10dB @ 55Hz |
| DRIVERS | 12” (300mm)/2.5” (63.5mm) voice coil LF driver 1” (25mm) exit HF compression driver |
| RATED POWER (2) | 300W AES, 1200W peak |
| RECOMMENDED AMPLIFIER | MA2.0 |
| SENSITIVITY (6) | 97dB |
| MAXIMUM SPL (9) | 122dB continuous, 128dB peak |
| NOMINAL IMPEDANCE | 8 ohms |
| DISPERSION (-6dB) | 80 ̊ horizontal, 50 ̊ vertical |
| CROSSOVER | 2.2 kHz passive |
| ENCLOSURE | 38 litre, multi-laminate birch ply |
| FINISH | Textured black paint |
| PROTECTIVE GRILLE | Black perforated steel |
| CONNECTORS | 2 x Neutrik NL4 |
| PIN CONNECTIONS | FR+,- : 1+,1- , Link thro’: 2+,2- |
| FITTINGS | 10 x M8, 4 x M8 threaded inserts 1 x mounting pole socket 1 x pocket handle |
| DIMENSIONS | (W) 398mm x (H) 571mm x (D) 365mm (W) 15.6ins x (H) 22.5ins x (D) 14.3ins |
| WEIGHT |
21kg (46lbs)
|
