MARTIN WISMAN MXM 602 EFX
Garantiramo najnižu cijenu na tržištu!
U slučaju da pronađete isti proizvod po povoljnijoj cijeni,
molimo Vas da nas kontaktirate na:
info@player.hr
2~4 mono input channels and 2 stereo input channels.
3-band frequency equalizer for each input channels.
Adopt low-noise discrete Mic pre-ampfier on microphone inputs.
Optional low cut filter to reduce low frequency interfere for mono input channels.
2 stereo inputs with 10dB input and record output.
Flexible monitor out and headphones output.
Peak indicator on each mono channel.
Provide +48V phantom power for condenser microphone.
Have a built-in 16 presets DSP effect processor.
lnputs Number Input modes Gonnector lnput lmpedance Rated lnput level
Mono MIC lN 2~4 Balanced XLR 2Kohm -60d8
Mono LINE lN 2~4 Balanced 3-poles TRS 47Kohm -40d8
UR LINE IN 2 Unbalanced 2 TRS 1OKohm -10dB
UR PI.AY IN 1 Unbalanced 2 RCA 1OKohm -10dB
Outputs Number Outputs modes Gonnector Outputs lmpedance Rated Output level
Stereo MAIN OUT 1 Unbalanced 2 TRS 75ohm +4dB
CTRL RM 1 Unbalanced 2 TRS 75ohm +4dB
AUX SEND 1 Unbalanced TRS 75ohm +4dB
Stero REC OT 1 Unbalanced 2 RCA 1 Kohm -1odB
HEADPHONE 1 Unbalanced 3-poles TRS 75ohm 3mW @35ohm
Channel EQ Hl 12KHz MID 2.5KHz LOW 80Hz max equalizing value +i-15dB
Low cut filter 80Hz 18dB/OCT
Total harmonic distortion <0.1o/o @+t+Og 20-20000H2 620ohm load
Frequency response +11-2dB @+4dB 20-20000H2620ohm load
Max out level +20d8 @0.5%THD l KHz 620ohm load
Microphone preamp E.l.N -124d8 @ 150ohm , at max gain
Power See the label on the adapter
Power consumption 7W
