MARTIN WISMAN PMF 1200
Garantiramo najnižu cijenu na tržištu!
U slučaju da pronađete isti proizvod po povoljnijoj cijeni,
molimo Vas da nas kontaktirate na:
info@player.hr
Ultra low noise discrete Mic Preamps with +48V Phantom Power;
Ultra-musical 3-band EQ on all channels;
Peak LEDs all Mono Channels;
1 Aux Send per channel for external effects;
Built in digital multi effect (16DSP);
2-Track Inputs assignable to Master Mix Output;
Highly accurate 10 segment Bargraph Meters;
1 Stereo master output and 1 Stereo Group output;
(Separate Master Mix Outputs)
Ultra low noise 12 channel Mic/Line Power Mixer
Features
12 Mono Input Channels with silver plated XLRs and balanced Line Inputs
Ultra low noise discrete Mic Preamps with +48V Phantom Power
Ultra-musical 3-band EQ on all channels
Peak LEDs all Mono Channels
1 Aux Send per channel for external effects
Built in digital multi effect (16DSP)
2-Track Inputs assignable to Master Mix Output
Highly accurate 10 segment Bargraph Meters
1 Stereo master output and 1 Stereo Group output
(Separate Master Mix Outputs)
Specifications
Channel MC Line: 12 MONO
Channel EQ: 3 BAND
Main Buses: 1 Stereo
Group Buses: 1 Stereo
Graphic EQ (Main): 2x7 Main
Phantom Power: +48V
Effect: 16DSP
Power Out: 350W + 350W
Dimensions: 650x530x160
|
Mono Inputs |
|
|
Mic Input |
Electronically balanced, discrete input configuration |
|
Bandwidth |
10Hz to 60kHz ±3dB |
|
Distortion (THD & N) |
0.01% at +4dBu, 1kHz, Bandwidth 80kHz |
|
Mic E.I.N (22Hz – 22kHz) |
-129.5 dBu, 150 Ohm source -117.3 dBqp, 150 Ohm source -132.0 dBu, input shorted -122.0 dBqp, input shorted |
|
TRIM range |
+10dB to +60dB |
|
Line Input |
Electronically balanced |
|
Bandwidth |
10Hz to 60kHz ±3dB |
|
Distortion (THD & N) |
0.01% at +4dBu, 1kHz, Bandwidth 80kHz |
|
Line level range |
+10dBu to -40dBu |
|
Equalization |
|
|
Hi Shelving |
12kHz +/-15dB |
|
Mid Range |
2.5kHz +/-15dB |
|
Lo Shelving |
80Hz +/-15dB |
|
Master Mix Section |
|
|
Max Output |
+22dBu balanced |
|
Aux Send Max Out |
+22 dBu unbalanced |
|
Control Room Out |
+22 dBu unbalanced |
|
Signal-To-Noise Ratio |
112dB, all channels at Unity gain |
|
Power supply |
|
|
Main voltage |
~220V AC, 50Hz |
|
Power |
350W + 350W |
