QSC RMX 5050

Šifra: 5412
2.787,05 EUR
*Cijena sa popustom može se ostvariti ukoliko se plaća gotovinom, virmanom (preko računa) ili debitnom i kreditnom karticom odmah i odjednom.
Prikazana cijena je za komad.

Garantiramo najnižu cijenu na tržištu!
U slučaju da pronađete isti proizvod po povoljnijoj cijeni,
molimo Vas da nas kontaktirate na:
info@player.hr

Prijavi povoljniju cijenu Obavijesti me ako cijena padne Postavi pitanje
Opcija:

QSC\'s RMX 5050 power amplifier represents the state-of-the-art in professional quality performance at an affordable price. Perfectly suited for a wide range of sound reinforcement applications including professional touring, performing musicians, and mobile entertainers, the RMX 5050 is optimized to deliver high levels of sustained power, extraordinary audio performance and road-proven reliability.Like its smaller sibling (the RMX 4050HD), the RMX 5050 features a three-tier, Class H design. The RMX 5050 is extremely efficient at real world power levels. Less AC current is wasted and more goes into producing useful audio power. The RMX 5050 uses the best available component upgrades to increase peak power by 25% over the RMX 4050HD.Like all RMX amps, the RMX 5050 features balanced 1/4\" TRS, XLR and barrier strip inputs, binding posts and Neutrik Speakon® outputs, front-mounted gain controls, plus signal and clip LED indicators to monitor performance.




BROJ 1 U AMERICI, DALEKO ISPRED SVIH !!!

2 x 2500 W NA 2 OHM !!!




RMX 5050



QSC\'s RMX 5050 power amplifier represents the state-of-the-art in professional quality performance at an affordable price. Perfectly suited for a wide range of sound reinforcement applications including professional touring, performing musicians, and mobile entertainers, the RMX 5050 is optimized to deliver high levels of sustained power, extraordinary audio performance and road-proven reliability.

Like its smaller sibling (the RMX 4050HD), the RMX 5050 features a three-tier, Class H design. The RMX 5050 is extremely efficient at real world power levels. Less AC current is wasted and more goes into producing useful audio power. The RMX 5050 uses the best available component upgrades to increase peak power by 25% over the RMX 4050HD.

Like all RMX amps, the RMX 5050 features balanced 1/4\" TRS, XLR and barrier strip inputs, binding posts and Neutrik Speakon® outputs, front-mounted gain controls, plus signal and clip LED indicators to monitor performance.



Amplifier Selector Tool

Need help choosing the right RMX Series amplifier for your speakers? Select your loudspeakers from over 200 of the most popular models to find out which amplifier will provide optimal performance.



FEATURES



  • The new flagship of the RMX line, the RMX 5050 provides extremely high power and represents tremendous value
  • The RMX 5050 provides advanced thermal performance, delivering higher continuous power in 2-ohms stereo or 4-ohms bridged applications
  • Dual mono, high current power supply for increased reliability and performance
  • 3RU chassis only 16\" deep
  • Professional quality performance - incorporates road-proven QSC designs
  • High-current toroidal transformers for greater two-ohm power and low noise
  • Independent user-defeatable clip limiters reduce distortion
  • Selectable low-frequency filters (30 Hz or 50 Hz) protect speakers and increase headroom
  • Balanced 1/4\" (6.3 mm) TRS, XLR, and barrier strip inputs for maximum flexibility
  • Binding post and Neutrik Speakon outputs
  • Front mounted gain controls for easy access
  • Signal and Clip LED indicators to monitor performance



SPECIFICATIONS

RMX 5050

  STEREO MODE, Both Channels Driven
8 ohms
  FTC 20 Hz - 20 kHz, 0.1% THD
  EIA 1 kHz, 0.1% THD

1050 W
1100 W
4 ohms
  FTC 20 Hz - 20 kHz, 0.1% THD
  EIA 1 kHz, 0.1% THD

1600 W
1800 W
2 ohms
  FTC 20 Hz-20 kHz 0.1% THD
  EIA 1 kHz 1% THD

2000 W
2500 W
  BRIDGE-MONO MODE
8 ohms
  FTC 20 Hz-20 kHz 0.1% THD
  EIA 1 kHz 0.1% THD

3200 W
3600 W
4 ohms
   EIA 1 kHz 1% THD

5000 W
Distortion (SMPTE-IM) Less than 0.02%
Distortion (Typical)
20 Hz - 20 kHz: 10 dB below rated power
1 kHz and below: full rated power

Less than 0.02%
Less than 0.02%
Frequency Response

20 Hz - 20 kHz, 8 ohms, LF filter bypassed, +0/-1 dB
5 Hz - 50 kHz, 8 ohms, LF filter bypassed, +0/-3 dB
Damping Factor Greater than 250 @ 8 ohm
Noise (unweighted) 100 dB below rated output (20 Hz - 20 kHz, 8 ohm load)
Input Sensitivity 1.42 Vrms for 1050 watts into 8 ohms
Voltage Gain 64x (36 dB) for 8 ohm load
Input Impedance 20k ohm balanced, 10k ohm unbalanced
Controls Front:
Controls Rear:

AC power switch, Ch. 1 and Ch. 2 gain control
10-pole DIP switch featuring LF filter on/off, LF filter 30/50 Hz, Clip Limiter on/off controls for each channel and switches for selecting Stereo, Parallel, or Bridge mode. Push-button circuit breaker for each channel.
Indicators

Power-On: Green LED, Protect: Red LED
Signal -30dB: Yellow LED, Clip: Red LED
Connectors Input:
Connectors Output:
XLR female, TRS (1/4\"), and barrier-strip screw terminals, each channel
Binding posts and Speakon® outputs (Ch. 1 Speakon wired for biamp)
Cooling Continuously variable-speed fan, rear-to-front air flow
Amplifier Protection

Short circuit, open circuit, thermal, ultrasonic, and RF protection. Stable into reactive or mismatched loads
Load Protection On/off muting, DC fault output crowbar
Power Requirements 100, 120 or 240 Volts AC (±10%) 50-60 Hz (factory configured)
120V models require 20 Amp service and are supplied with a NEMA 5-20 plug on the cordset.
Dimensions 19\" (48.3 cm) wide, 5.25\" (13.3 cm) tall, 15.9\" (40.39 cm) overall depth
Weight 75 lbs (34.02 kg) net, 87 lbs (39.46 kg) shipping



All Specification Subject to Change Without Notice.



Visit Pro Audio Review\'s website
for a review of QSC\'s RMX 5050 Amplifier.



Download QSC's catalogs as PDF files

2009 Full Line Product Catalog (4.3MB) NEW

2009 Catalogo Nueva Edicion (3.5MB)

2009 Cinema Products (5MB)
