Audient iD24 - zvučna kartica

Name: Audient iD24 - zvučna kartica - Player doo
Brand: Audient
SKU: 18440
Price: 332 RSD
Availability: schema.org
Rating: 88 (20 reviews)

Šifra: 18440

Regularna cijena:

398,00 EUR

Cijena sa popustom ^*

Cijena za kupovinu na rate:

Cijena sa popustom ^*

332,00 EUR

PDV je uračunat u cijenu

Iznos rate:

*Akcijska cijena (cijena sa popustom) vrijedi isključivo za plaćanje gotovinom, virmanom (uplatom na račun) ili jednokratnim plaćanjem debitnom ili kreditnom karticom. Navedeni uvjeti odnose se na ostvarivanje akcijske cijene te ne predstavljaju pravo na dodatni popust.

Prikazana cijena je za komad.

Garantiramo najnižu cijenu na tržištu!
U slučaju da pronađete isti proizvod po povoljnijoj cijeni,
molimo Vas da nas kontaktirate na:
info@player.hr

Dodaj na listu želja

Prijavi povoljniju cijenu Obavijesti me ako cijena padne Postavi pitanje

Opcija:

iD24 idealno je "10in/14out" 24-bit/96kHz audio sučelje za glazbenike, duete, tekstopisce, skladatelje i producente jer po super povoljnoj cijeni daje fantastične rezultate: od intuitivnog rukovanja, preko odličnih pretpojačala preuzetih s Audientovih konzola sve do konverzije zvuka koja će vjerno i neobojano prenijeti originalni zvuk. iD24 raspolaže svim važnim priključcima na koje ćete spojiti dva mikrofona, instrument i slušalice. Za razliku od manjeg modela, iD24 raspolaže i s dva dodatna izlaza. Uživajte u snimanju uz vrhunski zvuk kojeg vaše pjesme i zaslužuju!

Microphone Preamplifier

MIC GAIN: 0 to +58dB

MAXIMUM INPUT LEVEL: +12dBu

CROSSTALK: <-100dBu @ 1kHz & 10kHz

THD+N: @0dBu 1kHz: 0.0015%, -96dB

MIC EIN: -130dBu A-Weighted

CMRR: >75dB@1kHz

SNR: 97.5dB Unweighted, 100dB A-Weighted

FREQUENCY RESPONSE: +/- 0.5dB 10Hz to 40kHz

INPUT IMPEDANCE (Mic): 3kΩ balanced

INPUT IMPEDANCE (Line): 10kΩ balanced

PAD: -10dB

HPF CUTOFF FREQUENCY: 100Hz

PHANTOM POWER: 48V +/-4V @ 10mA/Channel

XLR COMBI FEMALE: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)

1/4” TRS JACK: TIP (Hot), RING (Cold) & SLEEVE (Shield)

Line Inputs

LINE GAIN:-10 to +48dB

MAXIMUM INPUT LEVEL:+22dBu

THD+N @0dBu 1kHz:0.0013%, -97dB

D.I / Instrument Input

D.I GAIN:0 to 58dB

MAXIMUM INPUT LEVEL:+12 dBu

THD+N @ 0dBu (1kHz):0.16%

SNR:95dB unweighted, 97.5dB A-weighted

FREQUENCY RESPONSE:+/- 0.5dB 0.5dB 10Hz to 40kHz

INPUT IMPEDANCE:500kΩ unbalanced

1/4” JACK:TIP (Hot) & SLEEVE (Shield)

Analogue to Digital Converter

MAXIMUM INPUT LEVEL:12.5dBu=0dBFS

CROSSTALK:@1k -135dB, @10k -125dB

FREQUENCY RESPONSE:+/- 0.2dB 0.5dB 10Hz to Fs/2 (Nyquist)

THD+N @ -1dBFS (1kHz):0.0004%, -108dB

DYNAMIC RANGE:122dB A-weighted

INPUT IMPEDANCE:>10kΩ

1/4” JACK:TIP (Hot), RING (Cold) & SLEEVE (Shield)

Digital to Analogue Converter

MAXIMUM OUTPUT LEVEL:12dBu=0dBFS

THD+N @ 1kHz -1dBFS:0.0003%, -110dB

DYNAMIC RANGE:126.5dB A-weighted

CROSSTALK:-130dB @ 1kHz, -115dB @ 10kHz

FREQUENCY RESPONSE:+/- 0.1dB 10Hz to Fs/2 (Nyquist)

OUTPUT IMPEDANCE:<100Ω

1/4” JACK:TIP (Hot), RING (Cold) & SLEEVE (Shield)

Headphone Outputs

MAXIMUM OUTPUT LEVEL:18.5dBu=0dBFS

THD+N @ -1dBFS (1kHz):0.0006%, -104dB

DYNAMIC RANGE:124dB A-weighted

CROSSTALK:-117dB @ 1kHz, -101dB @ 10kHz

FREQUENCY RESPONSE:+/- 0.2dB 10Hz to Fs/2 (Nyquist)

OUTPUT IMPEDANCE:<50Ω unbalanced

MAX LEVEL INTO 30R:2.63V Peak, 1.87V RMS, 232mW

MAX LEVEL INTO 60R:4.28V Peak, 3.03V RMS, 295mW

MAX LEVEL INTO 600R:7.91V Peak, 5.6V RMS, 104mW

USB-C High Speed

NO. OF INPUT CHANNELS:10 (2 Analogue, 8 Digital)

NO. OF OUTPUT CHANNELS:14 (6 Analogue, 8 Digital)

CONNECTOR:USB Type-C

INCLUDED CABLES:1m USB 2.0 Type-C to Type-C

Digital Input

8-CHANNEL ADAT:44.1kHz to 48kHz

4-CHANNEL ADAT:88.2kHz to 96kHz (SMUX)

STEREO S/PDIF44.1kHz to 96kHz (Stereo)

Digital Output

8-CHANNEL ADAT:44.1kHz to 48kHz

4-CHANNEL ADAT:88.2kHz to 96kHz (SMUX)

STEREO S/PDIF44.1kHz to 96kHz (Stereo)

DSP Mixer Latency

Round Trip (in-to-out)

44.1kHz:0.344ms

48kHz:0.312ms

88.2kHz:0.188ms

96kHz:0.177ms

Word Clock Output

WORD CLOCK OUTPUT:44.1kHz to 96kHz
